Drawer slides & lift systems
Order the drawer hardware together with your hinges, from the same factories, on one quote and one shipment.
What we can source
Tell us the drawer length, load and closing type. We confirm the exact model, finish and packing in writing before production.
- Ball-bearing slides
- Side-mounted, full or partial extension, soft-close or standard
- Concealed slides
- Undermount, full extension, soft-close or push-to-open
- Lift-up fittings
- Gas-strut and lift systems for wall cabinets with top-hinged doors
- What we need
- Drawer length, load, cabinet depth, quantity and destination
Combine with hinges
- One quote for hinges and slides
- Matching finish across the cabinet
- One shipment from the factory
Typical ranges
Tell us the drawer length, cabinet depth and the load you expect. We match the slide and confirm it in writing.
| Product | Lengths | Typical load | Closing |
|---|---|---|---|
| Ball-bearing side slide (45 mm wide) | 250–600 mm | about 35–45 kg per pair | Standard, soft-close or push-to-open |
| Concealed undermount slide | 250–550 mm | about 25–40 kg per pair | Soft-close or push-to-open |
| Heavy-duty ball-bearing slide | 300–1,000 mm | about 60–100 kg per pair | Standard or locking |
| Lift-up fitting / gas strut | By cabinet height | Chosen by door weight (strut force in N) | Stays open in position |
Figures are typical values for this product type. The exact specification, tolerances and test results for your model are confirmed in writing with your quote.
To quote slides we need
Cabinet depth
The slide length is usually the cabinet depth minus a small allowance.
Load
What goes in the drawer: cutlery, pots, files or tools.
Drawer side
Side thickness and material decide side-mount or undermount.
Have a hinge you need to match?
Send us a photo, a drawing or a product code. We will find matching options and reply within two business days.
